Automotive insert injection mould

Detailed Description

This mould is designed for insert molding. With a 1×2 cavity layout, precision insert positioning mechanisms (mechanical or magnetic) accurately place metal terminals, nuts, or bushings into the cavity before injection. The cold runner system avoids the risk of hot runner nozzles disturbing insert positions, making it ideal for small‑to‑medium batch, high‑precision automotive production.

Key features:

• Reliable insert positioning: custom locating pins or magnetic holders to prevent insert movement during injection

• 1×2 cavity design: balances efficiency and setup flexibility for varied insert products

• Runner design: pin gate or submarine gate for automatic or easy manual degating

• Protection option: insert presence sensor can be integrated to avoid mould damage from missing inserts

• Material compatibility: works with PA66, PBT, PPS and other engineering plastics (heat‑resistant, oil‑resistant)

Typical applications:

• Automotive sensor housing (with copper insert)

• Automotive connector (with terminals)

• Automotive relay base (with pins)

• Door latch actuator bracket (with nuts)
